Description
I/O TERMINAL BASIC V2
I/O TERMINAL OUTIL POUR LIRE ET ECRIRE LES CALCULATEUR
PEUGEOT CITROEN,VOLVO,FORD,VAG,JAGUAR,DAEWOO,OPEL, ECU FABRIQUER PAR SIEMENS
SID801 SID801A SID802 SID803 SID803A SID804 SID806 SID805 SID201 SID204 SIMOS7.1(A) SIMOS6.2 SIM210 SIM22 SIM24 SIM28 SIM29 SIMTEC71.1 SIMTEC75.5 SIEMENS/KEMSCO D3
LISTE DE MODELES SUPPORTE :
DAEWOO SIEMENS/KEMSCO D3
OPEL SIMTEC 71.1
OPEL SIMTEC 75.5
Land Rover Siemens SID201
Jaguar Siemens SID204
VAG Siemens SIMOS 6.2
VAG Siemens SIMOS 7.1
VAG Siemens SIMOS 7.1A
Ford Siemens SIM210 ECU Tool
Ford Siemens SIM22 ECU Tool
Ford Siemens SIM24 ECU Tool
Ford Siemens SIM28 ECU Tool
Ford Siemens SIM29 ECU Tool
Ford Siemens SID802 ECU Tool
Ford Siemens SID803 ECU Tool
Ford Siemens SID803A ECU Tool
Ford Siemens SID804 ECU Tool
Volvo Siemens SID803 ECU Tool
Volvo Siemens SID803A ECU Tool
PSA ECU Detect
PSA Siemens SID 201
PSA Siemens SID 801 ECU Tool
PSA Siemens SID 801A ECU Tool
PSA Siemens SID 802 ECU Tool
PSA Siemens SID 803 ECU Tool
PSA Siemens SID 803A ECU Tool
PSA Siemens SID 804 ECU Tool
PSA Siemens SID 805 ECU Tool
PSA Siemens SID 806 ECU Tool
NEWS
2013 10 04
FIAT/OPEL MAGNETI MARELLI Tool v32 released. 8GMW,8GMF HW502,8GMF HW503 ecus now supported. Corrected 6JO,6JF ecus software. Tool update I/O TERMINAL BASIC software v35 released. Made some modifications to SID803 ecus softwares.
2013 09 17
FIAT/OPEL MAGNETI MARELLI Tool v30 released. 8GSW ecu now supported. Corrected 8F2 CAN,8F3 CAN odometer change algorithm. Tool update I/O TERMINAL BASIC software v34 released. DAEWOO SIEMENS/KEMSCO D3 ecu now supported.
2013 08 10
MOTORCYCLE ECU TOOL1 V001 released.Tool Works with I/O TERMINAL HARDWARE. Tool for reading,writing full flash memories from DUCATI BIKES ECUS made by CONTINENTAL. All operations done by CAN no need to open ECU. ECUS supported CONTINENTAL M3C with freescale 9S12XDP256 mask 1L15Y, CONTINENTAL M3C with freescale 9S12XET256 mask 2M53J.
2013 08 10
FIAT/OPEL MAGNETI MARELLI Tool v29 released. Added ECUS support with SPANSION FLASH memories S29CL016 for FIAT Kline.
DUMP TOOL V2 (improved sid305 odometer correction by dump) released software can be downloaded from download page. Tool can be used by I/O TERMINAL users for free.
2013 07 13
Tool update I/O TERMINAL BASIC software v33 released. Ford SID804 mileage correction bug fix made. Software aivalable on downloads page . FIAT/OPEL MAGNETI MARELLI Tool v28 released. Added ECUS support with SPANSION FLASH memories S29CL016
2013 06 14
DUMP TOOL for sid206,sid305 ecus Odometer correction can be downloaded from download page. Tool corrects odometer in eeprom dump. Tool can be used by I/O TERMINAL users for free.
2013 05 19
Tool update FIAT BSI TOOL software v4 released. Magneti Marelli BSI (70F3633) from Fiat Grand Siena, Palio added.
2013 05 15
Tool update I/O TERMINAL BASIC software v32 released. Ford SID802,SID804 mileage correction added. Software aivalable on downloads page or you can download here
2013 05 08
Tool update FIAT/OPEL MAGNETI MARELLI Tool v26 released. Fiat 8GFS ECU now supported.
2013 05 04
FIAT BSI TOOL released. Works with I/O TERMINAL HARDWARE. Tool reads,writes eeprom memories and shows pincode stored in BSI. Tool works by OBD or wired bench. Currently BSIs supported : Magneti Marelli with Freescale MCU 3K91D,1k79X (R/W EEPROM SHOW PIN) . Magneti Marelli with NEC MCU 70F3237,70F3378 (R/W EEPROM SHOW PIN). Siemens Continental Freescale MCU 9S12DG128 (R/W EEPROM SHOW PIN).
2013 04 14
Tool update I/O TERMINAL BASIC software v30 released. Software aivalable on downloads page or you can download here
2013 03 27
Tool update FIAT/OPEL MAGNETI MARELLI Tool v25 released.
2013 03 12
I/O TERMINAL BASIC V2 software V28 is now . Added Ford SIM24, SIM28, SIM29 ECU support.
2013 03 10
Tool update FIAT/OPEL MAGNETI MARELLI Tool v24 released. 8GMF CAN ECUS with MPC5553 now supported. Download v24
2013 03 06
Tool update FIAT/OPEL MAGNETI MARELLI Tool v23 released. 8DF Kline ECUS with MPC5553 now supported.
2013 02 13
Tool update FIAT/OPEL MAGNETI MARELLI Tool v22 released. Made some corrections in FIAT Kline 6F3 and 8F2 CAN ECUs soft.
2013 02 12
Tool update FIAT/OPEL MAGNETI MARELLI Tool v21 released. Made some corrections in FIAT 6F3 and 8F2 ECUs soft.
2013 01 17
Tool update FIAT/OPEL MAGNETI MARELLI Tool v19 released. Added Fiat ECUs IAW 5SF3 CAN,Kline Emulated EEPROM R/W.
2012 12 18
Tool update FIAT/OPEL MAGNETI MARELLI Tool v18 released. Added Fiat ECUs MJD 8F2,MJD8F3 MPC5565 full flash R/W by CAN.
2012 12 02
Tool update FIAT/OPEL MAGNETI MARELLI Tool v17 released. Added Fiat ECUs support MJD 8F2,MJD8F3. Current functions eeprom 95640 R/W. Later will add other functions. Changed MJD 6JO,6JF ECUs MPC555 R/W functions. Now tool can clone MPC555 mcu like it would be done using BDM programmer
2012 11 27
Tool update FIAT/OPEL MAGNETI MARELLI Tool v16 released. Fixed some bugs related to IAW5SF8,IAW5SF9 ECUS. Changed MJD 6O2,6O3,6F3 ECUs MPC563 R/W functions. Now tool can clone MPC563 mcu like it would be done using BDM programmer
2012 11 27
Tool update FIAT/OPEL MAGNETI MARELLI Tool v15 released. Added new functions for IAW 5SF8, IAW 5SF9 ECUs Odometer change, Reset(Virgin).
2012 11 21
Tool update FIAT/OPEL MAGNETI MARELLI Tool v13 released. Added IAW 5SF8, IAW 5SF9 ECUs support by CAN . Now you can R/W ST10F296 internal flash memory full.
2012 11 16
Tool update FIAT/OPEL MAGNETI MARELLI Tool v10 released. Fixed some bugs and added FIAT ECU info read function.
2012 11 05
Tool update FIAT/OPEL MAGNETI MARELLI Tool v8 released. Added Fiat 6O2,6O3 (Functions – R/W 95320,MPC563,M58BW016 memories).
2012 11 04
Tool update FIAT/OPEL MAGNETI MARELLI Tool v7 released. Added Fiat 6F3 CAN ECUs (Functions – R/W 95320,MPC563,M58BW016 memories, change mileage,reset).
I/O TERMINAL Firmware FW_V11 released.
2012 11 04
Tool update FIAT/OPEL MAGNETI MARELLI Tool v6 released. Added Fiat 6F3 CAN ECUs (Functions – R/W 95320 eeprom, change mileage,reset).
2012 11 01
I/O TERMINAL BASIC V2 software V26 is now . New version of PSA SID804 there found by one user. Now I/O terminal compatible with that version of ECU.
2012 10 31
I/O TERMINAL BASIC V2 software V25 is now . Added support for Land Rover SID201 ecu. Now you can R/W eeprom 95320, R/W external flash M58BW016DB and R/W MPC563 flash. All operations work by CAN.
2012 10 31
Tool update FIAT/OPEL MAGNETI MARELLI Tool v5 released. Software works with I/O terminal hardware and activated online.
2012 10 25
Tool update FIAT/OPEL MAGNETI MARELLI Tool v4 released. Opel 6O2 CAN, Fiat 6JF, Fiat 6F3 ECUs now supported. Software works with I/O terminal hardware and activated online.
2012 10 07
Tool for reading/writing memories, reading pincode,changing mileage of opel magnetti marelli ecus(Z13DT,Z13DTJ,Z13DTH) by OBD or on bench. Software works with I/O terminal hardware and activated online.
2012 09 01
I/O TERMINAL BASIC V2 software V24 is now . Added support for Jaguar SID204 ecu. Now you can R/W eeprom 95320, R/W external flash M58BW016DB and R/W MPC563 flash. All operations work by CAN.
2012 07 02
I/O TERMINAL BASIC V2 software V23 is now . Added support for VAG SIMOS 6.2 ecu. Now you can R/W eeprom 95320, R/W external flash AM29BDD160GB and R/W MPC563 flash. All operations work by CAN.
2012 06 29
I/O TERMINAL BASIC V2 software V22 is now . Added support for VAG SIMOS 7.1, SIMOS 7.1A ecus. Now you can R/W eeprom 93C86 and R/W external flash 29F400BB. All operations work by Kline. Added Ford,Volvo SID803,SID803A mileage correction by CAN.
2012 05 07
New updated software for Renault ECU Tool released v1.03. Added special functions (Clear IMPACT DETECTED,Clear IMMO Code,Read KM) to SID301 ECU software. You can download it on downloads page. Also you will find there updated user manual and wiring diagrams.
2012 05 04
I/O TERMINAL BASIC V2 software V21 is now . Added support for PSA SID805 and Ford SIM210 ecus. Now you can R/W eeprom 93C56/ 93C86 and R/W external flash 29F400BB. All operations work by CAN.
2012 03 29
New software for Renault ECU Tool released v1.021.
2012 03 24
I/O TERMINAL BASIC V2 software V19 is now . Added support for Ford SIM22 ecu. Now you can R/W eeprom 93C86 and R/W external flash 29F400BB. All operations work by CAN.
New firmware FW_V09 released for I/O TERMINAL BASIC V2 and RENAULT CAN/K-Line ECU Tool.
2012 03 22
I/O TERMINAL BASIC V2 software V18 is now . Added support for Ford SID804 ecu. Now you can R/W eeprom 93C56 and R/W external flash 29F400BB. All operations work by CAN.
2012 03 21
I/O TERMINAL BASIC V2 software V17 is now . Added support for Ford SID802 ecu. Now you can R/W eeprom 93C56 and R/W external flash 29F400BB. All operations work by CAN.
2012 03 20
I/O TERMINAL BASIC V2 software V16 is now . Added support for Ford SID803,SID803A ecus. Now you can R/W eeprom 95320 and R/W external and internal flash memories. All operations work by CAN.
2012 03 18
I/O TERMINAL BASIC V2 software V15 is now . Corrected Volvo SID803A flash write function.
2012 02 21
New software for Renault ECU Tool released v1.02. You can find there user manual and wiring diagrams.
2011 10 27
Added support for Volvo SID803,SID803A ecus. Now you can R/W eeprom 95320 and R/W external and internal flash memories. All operations work by CAN.
